ball bearing
6305CM Ball Bearing
25x62x17
6305 CM Ball Bearing 25x62x17mm
B : Modified internal construction
We have 2260.00 sets in stock . If you have reuqirements for the bearings given as above,please feel free to contact us.We can assure you the best quality ;the most competitive prices ; the shortest delivery time and the highest quality service.
Product Model:
6305CM
Structure:
Deep Groove
Inside Diameter:
25 mm
Outside Diameter:
62 mm
Thickness:
17 mm
Seals Type:
Open
Material:
Bearing Steel
Precision Rating:
P0~P2
Brand:
Weight:
0.234 KG
Payment term:
T/T
Delivery time:
Within 3 Working Days
Product Description
M : Solid brass cage, ball-guide.
DB : Two deep groove ball bearings in O arrangement, matched clearance-free
DF : Two deep groove ball bearings in X arrangement, matched clearance-free
DT : Two deep groove ball bearings in tandem arrangement, matched clearance-free
2RSR : Lip seals on both sides
RSR: Lip seal on one side
BRS : Labyrinth seal
TVH : Cage made from glass fibre reinforced polyamide
Y : Sheet brass cage
2Z : Gap seals on both sides
Z : Gap seal on one side
d
25 mm
D
62 mm
B
17 mm
D1
50,2 mm
Da max
55 mm
d1
36,4 mm
da min
32 mm
ra max
1 mm
rmin
1,1 mm
m
0,234 kg
Mass
Cr
23800 N
Basic dynamic load rating, radial
C0r
11500 N
Basic static load rating, radial
nG
16200 1/min
Limiting speed
nB
12300 1/min
Reference speed
Cur
750 N
Fatigue limit load, radial
