New Designations : SX011824-A-VSP

Detailed parameters and installation dimensions:

Part Number: SX011824-A-VSP
Technical description (A-VSP): A= VSP=For Installation With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series Yrt With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary.
Bearing Type: Crossed Roller Bearings
Bearing Size (metric): Inner dia. (d): 120 mm X Outer dia. (D): 150 mm X Width (B): 16 mm or Size: 120 mm * 150 mm * 16 mm
Original Equipment Manufacture(OEM NO.): SX011824-A-VSP

Crossed Roller Bearings SX011824-A-VSP,  0.8 kg Bearing mass,  (120*150*16 mm),  120 mm d (Bore: diameter of the inner ring),  150 mm D (Outside: diameter of the outer cylindrical surface of the outer ring),  16 mm B (Width: nominal width of the bearing),
